R13LBEMG,R13LDESP,R13BGEHG,R13BJELP,R13BMEQW,R13SAETG,卡箍式減壓器

產品特點

系列中流量不銹鋼減壓器，單級式膜片減壓結構，不銹鋼膜片壓力傳輸，輸出壓力穩定，主要應用于大流量氣體系統，適用于純凈氣體、標準氣體、腐蝕性氣體等。

■ 設計特點

● 單級式減壓結構　　● 母體與膜片采用硬密封形式　　● 母體螺紋：進出氣接口3/4" NPT（F），壓力表，安全閥接口1/4〞NPT（F）　　● 內部結構易吹掃　　　● 內設過濾網　　　　 ● 可采用面板或墻式安裝

■ 適用范圍

● 氣體吹掃系統 　　● 特種氣體　　● 氣體匯流排　　● 石油化學工業

■ 特性參數

● 最大輸入壓力： 500，3000psig　　　　　　 ● 輸出壓力：0~15,0~25,0~70,0~125psig
● 安全測試壓力：1.5倍的最大進氣壓力　　　　● 適用溫度：-40℉~+165℉(-40℃~+74℃) 　　　● 泄漏率：2x10-8 atm cc/sec He
● CV值：1.8　　　● 重量：2.7kg

■ 材質

系列	R13L	R13B	R13S
母體	SS316L	Brass nickel plated	SS316L
上蓋	300 Series stainless steel	Brass nickel plated	300 Series stainless steel
墊片	PCTFE	PCTFE	PCTFE
閥桿	SS316L	SS316L	SS316L
膜片	SS316L	SS316L	SS316L

訂購指南

EX:R13	L	B	E	H	G	0 4	0 4	P
系列號	母體材質	母體孔位	輸入壓力	輸出壓力	壓力表	進氣形式	出氣形式	選項
R13	L：SS316L	A	E:1500 psig	H：0-125psig	G:附壓力表	04：1/2" NPT(F)	04：1/2" NPT(F)	P:面板式安裝
	B：Brass	B	F:500 psig	J： 0-75psig	（MPa）	05：1/2" NPT(M)	05：1/2" NPT(M)	R：安全閥
	S：SS304	D		L：0-25psig	P:附壓力表	06：3/4" NPT(F)	06：3/4" NPT(F)
		G		M：0~15psig	(psig/bar)	13：1/2"卡套接頭	13：1/2"卡套接頭
		J		Q：30〃Hg Vac-30psig	W:無壓力表	14：3/4"卡套接頭	14：3/4"卡套接頭
		M		S：30〃Hg Vac-60psig		其它形式接頭可供選擇	其它形式接頭可供選擇
				T：30〃Hg Vac-100psig
